Wireless motion detector

Wireless motion detector

home wireless pet-immunity pir sensor passive infrared sensor alarm
wireless pir sensor
wireless pir sensor
pir alarm sensor
pir alarm sensor

home wireless pet-immunity pir sensor passive infrared sensor alarm

Product Specification:
  • Place Of Origin : Shenzhen, Guangdong
  • Model : SR-616RIP
  • Material : ABS
  • Operating voltage : DC 3V (2*AA battery)
  • The warranty time : 2 yesrs
See Price
  1. Product Details

home wireless pet-immunity pir sensor passive infrared sensor alarm

The product is wireless intelligent pet-immunity detector with high stability. It has adopted advanced technology in signal processing, provided super high detection ability, function of automatically identify valve control and pulse count. The pir alarm sensor detector will detect movement of human auotomatically when intruder pass through the detector area, and it will send out alarm signal to alarm host if there is movement. The product suitable for the safety of residential house, villas, factories, markets, warehouses, office building etc.

Technical Parameters

Operating voltage DC 3V (2*AA battery)
Static current ≤15uA
Alarm current ≤10mA
Detecting distance 9~18m
Pet immunity 12kg
Detecting angle 110°
Code form 2262 or 1527
Radio frequency 315MHz or 433MHz
Radio distance 200m (open area)
Low battery indicator yellow LED
Alarm indicator red LED
Range of coverage 11 distance, 8 middle, 5 vicinities
Sensor dual element infrared sensor
Operating temperature -10℃ ~ +50℃
Environment humidity ≤ 95% RH (no congelation)
Anti RF interference 10MHz 1GHz 20V/m
Installation mode wall mounted or hanged in corner
Installation height 1.7 to 2.5m (2.2m is Proposed)
