Product Specification:
  • Place Of Origin : Shenzhen, Guangdong
  • Model Name : SR-P01series
  • AC power : 220VAC, 50 Hz
  • fire control panel zone : 4/8/16 Zones
See Price
  1. Product Details

fire alarm panel conventional fire alarm system fire alarm control panel

Product Description

The SR-P01 Series is Conventional Fire Alarm Control Panel, four to sixteen-zone(4/8/16 zones), Class B, Conventional Fire Alarm Control Panel. Designed exclusively to meet the latest market requirements and future ULC codes, the highly cost-effective SR-P01 Series can be used in a variety of low- to mid-sized applications.



Main features

Four, Eight, Sixteen Zone Style B (Class B) Initiating Device Circuits (IDCs), All zones accept
two-wire smoke detectors and any normally-open contact devices.
Two Supervisory Input with DC12V output, ideal to connect security alarm devices.
Three General Alarm, Trouble and Supervisory, Form A Relay Output.
One, Two, Four Built-in Sound Output, Style Y (Class B) Notification Appliance (Signal) Circuits
(NACs), NACs may be programmed: Silenceable or Non-Silenceable.
3.0 amps of total system power. Resettable DC24V & Non-resettable DC24V Output.
Zone Input Short Circuit can be set to “Alarm” or “ Fault” mode.
RS485 Communication Port (optional).
Automatic/Manual mode can be programmed.
Disable/Enable control per Zone (IDC) can be programmed.
Disable/Enable Sound Output(NACs) can be programmed.



Technical Parameters

AC POWER: 220VAC, 50 Hz.
BATTERY: Sealed lead-acid batteries only. Maximum charging circuit: 27.6VDC @ 0.8 amp for
normal flat charge. Maximum battery charger capacity: 18AH battery.
NOTE: Two 10AH batteries can be housed in the cabinet. Larger batteries require a separate battery box.
Total DC24V system power: 3.0 amps.
Maximum current per NAC: 1.25 amps.
Maximum battery charging capability: 18 AH.
Resettable four-wire smoke detector power output.
Non-resettable power output.
Integral Form-A Alarm, Trouble and Supervisory relays, rated at: 2.0 amps @ 30 VDC
(resistive), 2.0 amps @ 30 VAC (resistive)

commercial fire alarm system is also called fire control panelcommercial fire alarm system fire control panel with 4/8/16 zones Internal structure of the commercial fire alarm system fire control panelInternal structure for fire control panel and conventional fire alarm panelfire control panel and conventional fire alarm panelconventional fire alarm panel and commercial fire alarm systemcommercial fire alarm system and conventional fire alarm panelbest commercial fire alarm system fire control panelconventional fire alarm panel and commercial fire alarm system from sumringcommercial fire alarm system and conventional fire alarm panel with CEcommercial fire alarm system is also called fire control panel

FAQ:

Q1:Are you manufacture or trading company?
A1:We are a professional manufacture specialize in fire alarms such as fire control panels

Q2:What is the moq of the combustible gas leak detector?
A2:As usual,there is ready stock for our regular & hot selling models.
So any order quantity is welcome.

Q3:Can I customize LOGO and customized functions?
A3:Yes you can. Packaging, products, instructions can be printed logo. and functions we have professional R&D team to support best service.

Q4:How about the quality of your products?
A4:Our raw materials are purchased from qualified suppliers.

Q5:How long is the warranty time of the products?
A5:The warranty period is 2 years from the factory,if there are individual quality problems,
we will replenish the customer in the next batch of orders.
